Medical Gas Accessories • MGV Series

Suction Devices

Medicabay MGV Series suction devices bring controlled vacuum to the bedside: vacuum regulators with trap jar or hose connector, turbo regulators that make vacuum from medical air, trap jars, catheter holders, hoses and a vacuum trolley, made to BS, DIN and NF standards.

Key figures
psi · kPaDual scale gauge
2000 mlJar capacity
134 °CAutoclavable
BS · DIN · NFStandards

Every regulator to BS, DIN or NF standards; codes follow the Medicabay catalogue.

Regulators

Gradually adjustable vacuum, dual scale gauge and an on/off switch.

Turbo

Vacuum from medical air 4 or surgical air 7, without central vacuum.

Jars & trolley

200 cc traps, 2000 ml jars and a trolley for 2 or 4 jars.

Safety

Excess pressure safety valve and leak-proof connections.

Vacuum regulator with hose connection
MGV Series Products

Suction devices for every bedside

Vacuum regulators, jars and accessories, and a trolley for extended procedures.

Vacuum Regulator with Trap Jar
01 / 08 · With a 200 cc trap jar

Vacuum Regulator with Trap Jar

The vacuum regulator with trap jar gives precise suction control for patient aspiration, with a hose connection for secure transfer to the aspiration jar.

Gradually adjustable vacuum level for controlled, accurate suction; a dual scale gauge in psi and kPa, a high-pressure handwheel connector and an on/off switch. An integrated excess pressure safety valve prevents over-pressurisation; the robust brass body is available with different European connectors and inlets.

Vacuum
Gradually adjustable
Gauge
Dual scale, psi and kPa
Safety
Excess pressure safety valve
Trap jar
200 cc
Body
Brass
Order code
MGA.MGV.(norm).VI.T0VAC
Vacuum Regulator with Hose Connector
02 / 08 · Wall or rail type

Vacuum Regulator with Hose Connector

The vacuum regulator with hose connector connects straight to the aspiration jar for fluid collection, on the wall outlet or as a rail type with a hose to the outlet.

Gradually adjustable vacuum level for controlled, accurate suction; a dual scale gauge in psi and kPa, a high-pressure handwheel connector and an on/off switch. The rail type attaches securely to standard medical rails, saving space, and has a built-in excess pressure safety valve.

Versions
Wall or rail type
Vacuum
Gradually adjustable
Gauge
Dual scale, psi and kPa
Connection
High-pressure handwheel, hose connector
Order codes
MGA.MGV.(norm).VI.00VAC, rail MGA.MGV.R.(norm).VI.00VAC
Turbo Vacuum Regulator
03 / 08 · Vacuum from medical air 4 or surgical air 7

Turbo Vacuum Regulator

The turbo vacuum regulator converts medical air 4 or surgical air 7 into vacuum, ideal for facilities without a central vacuum system.

It comes with an integrated trap jar that collects fluids and protects the regulator, or with a hose connector. On/off switch, dual scale gauge and a leak-proof handwheel connector, with different European connectors and inlets.

Drive
Medical air 4 or surgical air 7
Versions
With trap jar or hose connector
Gauge
Dual scale, psi and kPa
Order codes
MGA.MGV.T.(norm).VI.T0VAC, MGA.MGV.T.(norm).VI.00VAC
Vacuum Trap 200cc
04 / 08 · Protects the vacuum system

Vacuum Trap 200cc

The 200 cc vacuum trap traps fluids and keeps them out of the vacuum system, protecting the equipment.

Impact-resistant polycarbonate with precision seals for a leak-proof, hygienic operation; transparent for easy fluid level monitoring and autoclavable up to 134 °C.

Capacity
200 cc
Material
Polycarbonate
Sterilisation
Autoclavable up to 134 °C
Order code
MGA.MGV.PC.T00O2
Vacuum Trap Jar 2000 ml with Rail Mounting
05 / 08 · Large capacity on the rail

Vacuum Trap Jar 2000 ml with Rail Mounting

The 2000 ml vacuum jar gives a large fluid collection capacity, so it needs emptying less often, and mounts on medical rails with a plastic rail mounting apparatus.

Durable, impact-resistant polycarbonate with a leak-proof seal, a clear body for fluid level monitoring and autoclavable up to 134 °C.

Capacity
2000 ml
Mounting
Plastic rail holder apparatus
Material
Polycarbonate
Sterilisation
Autoclavable up to 134 °C
Order code
Rail holder MGA.RAIL.H0001
Catheter Holder with Rail Mounting
06 / 08 · Keeps the catheter in place

Catheter Holder with Rail Mounting

The catheter holder holds catheters firmly in place, preventing displacement during procedures, and attaches to medical equipment rails.

Compact, lightweight and strong, in durable polycarbonate; easy to clean and autoclavable up to 134 °C.

Mounting
Plastic rail mounting
Material
Polycarbonate
Sterilisation
Autoclavable up to 134 °C
Order code
MGA.CTH.H0001
Silicone & Medical Gas Hoses
07 / 08 · For vacuum jars and every medical gas

Silicone & Medical Gas Hoses

The silicone hose for vacuum jars is medical-grade, biocompatible, non-toxic and latex-free, withstands sterilisation temperatures and fits tightly to regulators and suction jars.

The medical gas hoses, 6 × 12 mm, are colour coded for their gas so the right gas is always connected: oxygen white, nitrous oxide blue, medical air black, vacuum yellow. Flexible and durable, they work from −40 °C to +200 °C with a smooth inner surface.

Silicone hose
Medical grade, latex-free, autoclavable
Medical gas hoses
6 × 12 mm; O₂ white, N₂O blue, air black, vacuum yellow
Temperature
−40 °C to +200 °C
Order codes
MGA.SLC.H0001, MGA.PVC.PND.V0001
Vacuum Trolley with Jars
08 / 08 · 2 or 4 jars of 2000 ml

Vacuum Trolley with Jars

The vacuum trolley carries 2 or 4 vacuum jars of 2000 ml for extended procedures, with a vacuum regulator or a turbo vacuum regulator for controlled suction.

A light, sturdy aluminium frame on five 50 mm caster wheels moves easily; silicone hoses give secure, hygienic fluid transfer, and the jars have clear graduated markings.

Jars
2 or 4 × 2000 ml
Regulator
Vacuum or turbo vacuum regulator
Frame
Aluminium
Wheels
Five 50 mm casters
Order codes
MGA.MGV.T.(2/4).(norm).VI.T0VAC, turbo MGA.MGV.T.TR.(2/4).(norm).VI.T0VAC
Regulators are supplied with the connector of the norm you choose.
Design & Construction

Controlled, safe suction

Precise vacuum for patient aspiration, with jars that protect the system.

01

Precise vacuum

Gradually adjustable vacuum level for accurate suction.

02

Dual scale gauge

Pressure readings in psi and kPa.

03

Safety valve

Excess pressure safety valve prevents over-pressurisation.

04

Turbo regulators

Vacuum from medical air 4 or surgical air 7, without central vacuum.

05

Autoclavable jars

Polycarbonate traps and jars, autoclavable up to 134 °C.

06

Built to standards

Manufactured according to BS, DIN and NF standards.

Safety & Technical Data

Standards & Technical Specifications for Suction Devices

Common to the MGV Series suction devices.

Vacuum Control

psi & kPa Gauge

Gradually adjustable vacuum, dual scale gauge, on/off switch and an excess pressure safety valve.

Jars

200 cc & 2000 ml

Polycarbonate traps and jars, leak-proof and autoclavable up to 134 °C.

Standards

BS, DIN & NF

Regulators with connectors to BS, DIN or NF and different European inlets.

Quality Management

ISO 13485 & ISO 9001

Manufactured under Medicabay’s ISO 13485 medical device and ISO 9001 quality management systems.

MGV Series Request List

Build your suction device list

Tick every product you need, choose the norm and version and the quantity; the code appears with each one. Then request them together.

1Tick the products you need
1
1
1
1
1
1
1
Oxygen (O₂), white
0
Nitrous oxide (N₂O), blue
0
Medical air, black
0
Vacuum, yellow
0
1
Knowledge Base & Specifications

Suction Devices FAQs

Clinical, installation and engineering answers about Medicabay Suction Devices.

What is a turbo vacuum regulator?

A regulator that converts medical air 4 or surgical air 7 into vacuum, for facilities without a central vacuum system.

Which vacuum regulators are available?

With a 200 cc trap jar or with a hose connector, as wall or rail type, and turbo regulators with trap jar or hose connector.

Can the jars be sterilised?

Yes. The polycarbonate traps and 2000 ml jars are autoclavable up to 134 °C.

What does the vacuum trolley carry?

2 or 4 vacuum jars of 2000 ml with a vacuum or turbo vacuum regulator, on an aluminium frame with five 50 mm casters.

Which standards are available?

BS, DIN and NF, with different European connectors and inlets.

Request a quote

Planning a project with Suction Devices?

Tell us about your facility and our team will prepare a tailored offer and technical documentation.
